Mechanical
| Detail | |
|---|---|
| Dimension | 186mm(W) × 186mm(H) × 37mm(D) |
| Environment | Indoor |
| Enclosure material | Plastic |
| Mount material | Plastic |
Hardware
| Detail | |
|---|---|
| Management interfaces | Ethernet, Wireless |
| Networking Interface |
1 GbE WAN 10/100/1000BASE-T autosensing (RJ-45)
1 Console (RJ-45) |
| Buttons | 1 Reset button |
| Power Method | IEEE802.3at PoE (included), DC 12V @ 1.5A |
| Power Save | Supported |
| Max Power Consumption | 14W |
| Operating Frequency |
2.4 GHz : 2.400-2.483,5 MHz (Ch Width 20/40 MHz)
5 GHz : 5.150-5.250 MHz 5.250-5.350 MHz5.725-5.825 MHz (Ch Width 20/40/80/160 MHz) |
| TX Power (±2dBm) |
18 dBm @ 2.4 GHz (per chain)
18 dBm @ 5 GHz (per chain) |
| Chipset | Qualcomm |
| Antennas | |
|---|---|
| 2.4 GHz | MIMO 2x2 4dBi (omni antenna) |
| 5 GHz | MU MIMO 2x2 4dBi (omni antenna) |
| Radio Rate | |
|---|---|
| 2.4 GHz | Up To 573.6 Mbps |
| 5 GHz | Up To 2400 Mbps |
| Mounting & Environment | |
|---|---|
| Operating Temperature | 0° C to 45° C |
| Operating Humidity | 5 to 95% non-condensing |
Software
| Detail | |
|---|---|
| Wi-Fi Standards | 802.11a/b/g/n/ac/ax |
| Wireless Security | WPA/WPA2/WPA3, TKIP/AES |
| Personal, Enterprise | |
| BSSID | Up To 2x8 SSID |
| Certifications | SDPPI, P3DN (TKDN) |
| VLAN | 802.1Q |
| Band Steering | Supported |
| Advanced QoS | Per-User Rate Limiting |
| Guest Traffic Isolation | Supported |
| WMM | Available |
| Concurrent Clients | 250+ |
| Software Guide | Cluster, ESP Cloud, VOLTECH Free Cloud |
